Introducing new Dental Light
As adopting latest technology, Luvis C500 bring various new feature to users: Selectable color temperature / wider focus / sensor(on/off, Intensity control).
In addition, internal camera / resin mode cover / remote controller will be selected by users. Adding this feature on benefit from LED will help the doctor and patients in their good conditions.
In addition, internal camera / resin mode cover / remote controller will be selected by users. Adding this feature on benefit from LED will help the doctor and patients in their good conditions.
Introducing new Dental Light
As adopting latest technology, Luvis C500 bring various new feature to users: Selectable color temperature / wider focus / sensor(on/off, Intensity control).
In addition, internal camera / resin mode cover / remote controller will be selected by users. Adding this feature on benefit from LED will help the doctor and patients in their good conditions.
In addition, internal camera / resin mode cover / remote controller will be selected by users. Adding this feature on benefit from LED will help the doctor and patients in their good conditions.
High Color Rendering Index (CRI)
Luvis suggests high CRI of Ra 95 which may realize more clear and nature-like color. It helps to reduce the eye fatigue compared to higher brightness with low CRI.
Easy to Control
Luvis C500 brings two types of control. Conventional controller is located on the back panel of the light. From the front, the user can control On/Off, Intensity by sensor.
Selectable Color Temperature
3 Steps of color temperature (4,000K/4,500K/5,000K) adjustment will help doctors to find more suitable and comfortable light color.
Wider Focus
With its highest level of uniformity (d50/d10>75) and wider focal pattern, Luvis C500 delivers stable intensity and quality light to the focal side.
Detachable Main Handle
It can be used inside an autoclave without damage.
New Feature
Technical Specification
| Classification | Unit | Specification | Reference | |
|---|---|---|---|---|
| Centre intensity | Min | Lux | 3,000 Lux | @ 4,500K |
| (@ 70Cm) | Max | Lux | 50,000 Lux | |
| Focal Distance | Cm | 70 | ||
| Focal Pattern (@ d10) | Cm | 16.0 x 9.0 | Oval Shape | |
| Focal Pattern (@ d50) | Cm | 12.7 x 6.7 | Oval Shape | |
| Uniformity (d50/d10) | N/A | < 75% | ||
| Color temperature (3 steps) | K | 4,000/4,500/5,000 | Selectable | |
| C.R.I(Ra) | N/A | 95 | @ 4,000K | |
| Input Voltage | AC12-18V | 50/60Hz | ||
| DC15V 4.0A | Camera Type / Using Adapter |
|||
| Consumption | <30W | |||
| LED life time | 50,000LUX | |||
| Camera | Specification |
|---|---|
 |
|
| Image Sensor | 1 / 2.8″ CMOS |
| Lens | 30x Optical zoom |
| Image Point | 2.38 M Pixel |
| Object Distance (Min.) | 600~800mm (Tele end) |
| Video Signal | HD-SDI Coaxial cable 1080p/1080i/720p |
High Color Rendering Index (CRI)
Luvis suggests high CRI of Ra 95 which may realize more clear and nature-like color. It helps to reduce the eye fatigue compared to higher brightness with low CRI.
Easy to Control
Luvis C500 brings two types of control. Conventional controller is located on the back panel of the light. From the front, the user can control On/Off, Intensity by sensor.
Selectable Color Temperature
3 Steps of color temperature (4,000K/4,500K/5,000K) adjustment will help doctors to find more suitable and comfortable light color.
Wider Focus
With its highest level of uniformity (d50/d10>75) and wider focal pattern, Luvis C500 delivers stable intensity and quality light to the focal side.
Detachable Main Handle
It can be used inside an autoclave without damage.
New Feature
Technical Specification
| Classification | Unit | Specification | Reference | |
|---|---|---|---|---|
| Centre intensity | Min | Lux | 3,000 Lux | @ 4,500K |
| (@ 70Cm) | Max | Lux | 50,000 Lux | |
| Focal Distance | Cm | 70 | ||
| Focal Pattern (@ d10) | Cm | 16.0 x 9.0 | Oval Shape | |
| Focal Pattern (@ d50) | Cm | 12.7 x 6.7 | Oval Shape | |
| Uniformity (d50/d10) | N/A | < 75% | ||
| Color temperature (3 steps) | K | 4,000/4,500/5,000 | Selectable | |
| C.R.I(Ra) | N/A | 95 | @ 4,000K | |
| Input Voltage | AC12-18V | 50/60Hz | ||
| DC15V 4.0A | Camera Type / Using Adapter |
|||
| Consumption | <30W | |||
| LED life time | 50,000LUX | |||
| Camera | Specification |
|---|---|
|
|
| Image Sensor | 1 / 2.8″ CMOS |
| Lens | 30x Optical zoom |
| Image Point | 2.38 M Pixel |
| Object Distance (Min.) | 600~800mm (Tele end) |
| Video Signal | HD-SDI Coaxial cable 1080p/1080i/720p |
· Examination Mode
· Color Rendering Index
· Illumination Intensity
· Color Temperature
· Light Field Size
· Color Rendering Index
· Illumination Intensity
· Color Temperature
· Light Field Size
· Examination Mode
· Color Rendering Index
· Illumination Intensity
· Color Temperature
· Light Field Size
· Color Rendering Index
· Illumination Intensity
· Color Temperature
· Light Field Size
ARM Touch Control (4.3″ LCD Panel)
Dental Mode
– Dental Light ON/OFF
– Intensity Control
OT Light 1 or 2 Control (Sync)
– Light 1 / Light 2 Select
– Light ON/OFF
– Light Field Size, Intensity Color Temp
– Light ON/OFF
Max. Mode_OT Light
– Light Field Size 3 Level and Intensity 3 Level Setting
Examination Mode
– Examin. Light ON/OFF
– Intensity, Color Temp. Control
Sync Mode
– OT Light (1 and 2) Sync
Technical Specification
| Class | S300 Specification |
|---|---|
| Installation | Single Ceiling |
| Dual Ceiling | |
| Mobile | |
| Head Size (cm) | 43.5 |
| Installation | 42 |
| Intensity (lx) | 130,000 |
| Intensity Control | 3 Steps (40,000~130,000) |
| C.R.I (Ra/R9) | 96 / 95 |
| Color Temp. (K) | 3,800 / 4,300 / 4,800 |
| Light Field Size (cm) | 3 Steps (15~25, Circle) |
| Detachable Centre Grip | Yes (2X) |
| Input Power | 100~240Vac, 50/60Hz |
| LED Life(Hrs) | 60,000 |
| Option | Wall Controller (Tablet PC) |
| Backup Battery |
| Class | Back-up Battery Specification |
|---|---|
| Rating | 20~28Vdc, 4A |
| (Lithium-ion Battery) | |
| Dimension | 244x164x120mm |
| Weight | 3.8kg |
New Feature
– Over Voltage Detection
– Under Voltage Detection
– Discharging Over Current Detection
– Short Circuit Detection
– Cell Balancing, PTC
– Life cycle: 300 cycle (charge/discharge)
– Duration: 3 hours
ARM Touch Control (4.3″ LCD Panel)
Dental Mode
– Dental Light ON/OFF
– Intensity Control
OT Light 1 or 2 Control (Sync)
– Light 1 / Light 2 Select
– Light ON/OFF
– Light Field Size, Intensity Color Temp
– Light ON/OFF
Max. Mode_OT Light
– Light Field Size 3 Level and Intensity 3 Level Setting
Examination Mode
– Examin. Light ON/OFF
– Intensity, Color Temp. Control
Sync Mode
– OT Light (1 and 2) Sync
Technical Specification
| Class | S300 Specification |
|---|---|
| Installation | Single Ceiling |
| Dual Ceiling | |
| Mobile | |
| Head Size (cm) | 43.5 |
| Installation | 42 |
| Intensity (lx) | 130,000 |
| Intensity Control | 3 Steps (40,000~130,000) |
| C.R.I (Ra/R9) | 96 / 95 |
| Color Temp. (K) | 3,800 / 4,300 / 4,800 |
| Light Field Size (cm) | 3 Steps (15~25, Circle) |
| Detachable Centre Grip | Yes (2X) |
| Input Power | 100~240Vac, 50/60Hz |
| LED Life(Hrs) | 60,000 |
| Option | Wall Controller (Tablet PC) |
| Backup Battery |
| Class | Back-up Battery Specification |
|---|---|
| Rating | 20~28Vdc, 4A |
| (Lithium-ion Battery) | |
| Dimension | 244x164x120mm |
| Weight | 3.8kg |
New Feature
– Over Voltage Detection
– Under Voltage Detection
– Discharging Over Current Detection
– Short Circuit Detection
– Cell Balancing, PTC
– Life cycle: 300 cycle (charge/discharge)
– Duration: 3 hours
· 3 Different Modes
· Color Rendering Index
· Illumination Intensity
· Color Temperature
· Light Field Size
· Color Rendering Index
· Illumination Intensity
· Color Temperature
· Light Field Size
· 3 Different Modes
· Color Rendering Index
· Illumination Intensity
· Color Temperature
· Light Field Size
· Color Rendering Index
· Illumination Intensity
· Color Temperature
· Light Field Size
ARM Touch Control (5″ LCD Panel)
Light Control
– Brightness(Intensity) 3 Steps
– Light Field Size 3 Steps
– Color Temp. 3 Steps
OT Light 1 or 2 Control (Sync)
– Light 1 / Light 2 Select
– Light ON/OFF
– Light Field Size, Intensity Color Temp
Sync Mode
– OT Light (1 and 2) Sync
Max. Mode
– OT Light
– Light Field Size 3 Level and Intensity 3 Level Setting
Examination Mode
– Examin. Light ON/OFF
– Intensity, Color Temp. Control
Camera Mode
Camera Control Button
– Zoom In/Out (Ratio: 30X)
– Focus In/Out, Auto
– Brightness up/down, Auto
Freeze
– Camera Freezing Button
Camera On/Off
– The Camera turns on, at the last condition
stored in its memory
White balance
– White balance control button
Technical Specification
| Class | S300 Specification |
|---|---|
| Installation | Single Ceiling |
| Dual Ceiling | |
| Mobile | |
| Head Size (cm) | 43.5 |
| Installation | 42 |
| Intensity (lx) | 130,000 |
| Intensity Control | 3 Steps (40,000~130,000) |
| C.R.I (Ra/R9) | 96 / 95 |
| Color Temp. (K) | 3,800 / 4,300 / 4,800 |
| Light Field Size (cm) | 3 Steps (15~25, Circle) |
| Detachable Centre Grip | Yes (2X) |
| Input Power | 100~240Vac, 50/60Hz |
| LED Life(Hrs) | 60,000 |
| Option | Wall Controller (Tablet PC) |
| Backup Battery |
| Class | Full-HD Camera |
|---|---|
| Image Sensor | 1/2.8-Type CMOS |
| Lens | 30X Optical Zoom |
| Image Point | Approx. 2.13 Megapixels |
| Output Pixels | Full HD 1080p (1,920X1,080) |
| Video Signal | Digital: HD-SDI (BNC) |
| Class | Back-up Battery Specification |
|---|---|
| Rating | 20~28Vdc, 4A |
| (Lithium-ion Battery) | |
| Dimension | 240x140x120mm |
| Weight | 3.8kg |
ARM Touch Control (5″ LCD Panel)
Light Control
– Brightness(Intensity) 3 Steps
– Light Field Size 3 Steps
– Color Temp. 3 Steps
OT Light 1 or 2 Control (Sync)
– Light 1 / Light 2 Select
– Light ON/OFF
– Light Field Size, Intensity Color Temp
Sync Mode
– OT Light (1 and 2) Sync
Max. Mode
– OT Light
– Light Field Size 3 Level and Intensity 3 Level Setting
Examination Mode
– Examin. Light ON/OFF
– Intensity, Color Temp. Control
Camera Mode
Camera Control Button
– Zoom In/Out (Ratio: 30X)
– Focus In/Out, Auto
– Brightness up/down, Auto
Freeze
– Camera Freezing Button
Camera On/Off
– The Camera turns on, at the last condition
stored in its memory
White balance
– White balance control button
Technical Specification
| Class | S300 Specification |
|---|---|
| Installation | Single Ceiling |
| Dual Ceiling | |
| Mobile | |
| Head Size (cm) | 43.5 |
| Installation | 42 |
| Intensity (lx) | 130,000 |
| Intensity Control | 3 Steps (40,000~130,000) |
| C.R.I (Ra/R9) | 96 / 95 |
| Color Temp. (K) | 3,800 / 4,300 / 4,800 |
| Light Field Size (cm) | 3 Steps (15~25, Circle) |
| Detachable Centre Grip | Yes (2X) |
| Input Power | 100~240Vac, 50/60Hz |
| LED Life(Hrs) | 60,000 |
| Option | Wall Controller (Tablet PC) |
| Backup Battery |
| Class | Full-HD Camera |
|---|---|
| Image Sensor | 1/2.8-Type CMOS |
| Lens | 30X Optical Zoom |
| Image Point | Approx. 2.13 Megapixels |
| Output Pixels | Full HD 1080p (1,920X1,080) |
| Video Signal | Digital: HD-SDI (BNC) |
| Class | Back-up Battery Specification |
|---|---|
| Rating | 20~28Vdc, 4A |
| (Lithium-ion Battery) | |
| Dimension | 240x140x120mm |
| Weight | 3.8kg |
